Аналоговый компаратор LM6511IM Texas Instruments

Артикул:

LM6511IM

Производитель: Texas Instruments

Описание: Аналоговый компаратор LM6511IM Texas Instruments

Datasheet:

Характеристики

Manufacturer Texas Instruments

Number of Channels 1 Channel

CMRR - Common Mode Rejection Ratio 72 dB

Comparator Type General Purpose

GBP - Gain Bandwidth Product -

Height 1.45 mm

Ib - Input Bias Current 130 nA

Length 4.9 mm

Maximum Operating Temperature + 85 C

Minimum Operating Temperature - 40 C

Mounting Style SMD/SMT

Operating Supply Current 3.5 mA

Operating Supply Voltage 3 V, 5 V, 9 V, 12 V, 15 V, 18 V, 24 V, 28 V

Output Type Open Collector

Package/Case SOIC-8

Pd - Power Dissipation 500 mW (1/2 W)

Product Analog Comparators

Response Time 180 ns

Supply Type Single

Supply Voltage - Max 30 V

Supply Voltage - Min 2.5 V

Technology Bipolar

Type Voltage Comparator

Unit Weight 143 mg

Vcm - Common Mode Voltage 0.5 V

Voltage Gain dB 92.04 dB

Vos - Input Offset Voltage 5 mV

Width 3.9 mm
