Аналоговый компаратор LMH7322SQ/NOPB Texas Instruments

Артикул:

LMH7322SQ/NOPB

Производитель: Texas Instruments

Описание: Аналоговый компаратор LMH7322SQ/NOPB Texas Instruments

Datasheet:

Характеристики

Manufacturer Texas Instruments

Number of Channels 2 Channel

CMRR - Common Mode Rejection Ratio 80 dB

Comparator Type General Purpose

Dual Supply Voltage +/- 3 V, +/- 5 V

GBP - Gain Bandwidth Product -

Height 0.8 mm

Ib - Input Bias Current 5 uA

Length 4 mm

Maximum Dual Supply Voltage +/- 6 V

Maximum Operating Temperature + 125 C

Minimum Dual Supply Voltage +/- 1.35 V

Minimum Operating Temperature - 40 C

Moisture Sensitive Yes

Mounting Style SMD/SMT

Operating Supply Current 20 mA

Operating Supply Voltage 3 V, 5 V, 9 V

Output Type Complementary

Package/Case WQFN-24

Product Analog Comparators

Propagation Delay Time 783 ps

PSRR - Power Supply Rejection Ratio 80 dB

Supply Type Single, Dual

Supply Voltage - Max 12 V

Supply Voltage - Min 2.7 V

Technology Bipolar

Type High Speed Comparator

Unit Weight 48 mg

Vcm - Common Mode Voltage 0.2 V

Voltage Gain dB 53 dB

Vos - Input Offset Voltage 8 mV

Width 4 mm
