Аналоговый компаратор LP339DG4 Texas Instruments

Артикул:

LP339DG4

Производитель: Texas Instruments

Описание: Аналоговый компаратор LP339DG4 Texas Instruments

Datasheet:

Характеристики

Manufacturer Texas Instruments

Number of Channels 4 Channel

Comparator Type General Purpose

Dual Supply Voltage +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V

GBP - Gain Bandwidth Product -

Height 1.58 mm

Ib - Input Bias Current 25 nA

Length 8.65 mm

Maximum Dual Supply Voltage +/- 15 V

Maximum Operating Temperature + 70 C

Minimum Dual Supply Voltage +/- 1.5 V

Minimum Operating Temperature 0 C

Mounting Style SMD/SMT

Operating Supply Current 25 uA

Operating Supply Voltage 5 V to 30 V

Output Current per Channel 20 mA

Output Type Rail-to-Rail

Package/Case SOIC-14

Product Analog Comparators

Reference Voltage No

Response Time 1.3 us

Supply Type Single, Dual

Supply Voltage - Max 30 V

Supply Voltage - Min 5 V

Technology Bipolar

Type Low Power Comparator

Unit Weight 122,400 mg

Voltage Gain dB 113.98 dB

Vos - Input Offset Voltage 5 mV

Width 3.91 mm
