Аналоговый компаратор MAX901BCPE+ Maxim Integrated

Артикул: MAX901BCPE+

Производитель: Maxim Integrated

Описание: Аналоговый компаратор MAX901BCPE+ Maxim Integrated

Datasheet:

Характеристики

Manufacturer Maxim Integrated

Number of Channels 2 Channel

CMRR - Common Mode Rejection Ratio 82.5 dB

Comparator Type General Purpose

Dual Supply Voltage +/- 3 V

GBP - Gain Bandwidth Product -

Height 4.45 mm (Max)

Ib - Input Bias Current 10 uA

Length 19.43 mm (Max)

Maximum Dual Supply Voltage +/- 5 V, 7 V

Maximum Operating Temperature + 70 C

Minimum Dual Supply Voltage +/- 2.5 V

Minimum Operating Temperature 0 C

Mounting Style Through Hole

Operating Supply Current 15 mA

Operating Supply Voltage 9 V

Output Type TTL

Package/Case PDIP-16

Pd - Power Dissipation 500 mW (1/2 W)

Product Analog Comparators

Propagation Delay Time 10 ns

PSRR - Power Supply Rejection Ratio 80 dB

Response Time 8 ns

Supply Type Single, Triple

Supply Voltage - Max 10 V

Supply Voltage - Min 5 V

Type Voltage Comparator

Unit Weight 1,628 g

Vos - Input Offset Voltage 4 mV

Width 7.87 mm (Max)
