Аналоговый компаратор MAX902ESD+ Maxim Integrated

Артикул: MAX902ESD+

Производитель: Maxim Integrated

Описание: Аналоговый компаратор MAX902ESD+ Maxim Integrated

Datasheet:

Характеристики

Manufacturer Maxim Integrated

Number of Channels 2 Channel

CMRR - Common Mode Rejection Ratio 82.5 dB

Comparator Type General Purpose with Latch

Dual Supply Voltage +/- 3 V

GBP - Gain Bandwidth Product -

Height 1.5 mm (Max)

Ib - Input Bias Current 10 uA

Length 8.75 mm (Max)

Maximum Dual Supply Voltage +/- 5 V, 7 V

Maximum Operating Temperature + 85 C

Minimum Dual Supply Voltage +/- 2.5 V

Minimum Operating Temperature - 40 C

Mounting Style SMD/SMT

Operating Supply Current 8 mA

Operating Supply Voltage 9 V

Output Current per Channel -

Output Type Complementary

Package/Case SOIC-14

Pd - Power Dissipation 500 mW (1/2 W)

Product Analog Comparators

Propagation Delay Time 8 ns

PSRR - Power Supply Rejection Ratio 80 dB

Response Time 8 ns

Supply Type Single, Triple

Supply Voltage - Max 10 V

Supply Voltage - Min 5 V

Type Voltage Comparator

Unit Weight 338 mg

Vos - Input Offset Voltage 4 mV

Width 4 mm (Max)
