Аналоговый компаратор MAX9202ESD+ Maxim Integrated

Артикул: MAX9202ESD+

Производитель: Maxim Integrated

Описание: Аналоговый компаратор MAX9202ESD+ Maxim Integrated

Datasheet:

Характеристики

Manufacturer Maxim Integrated

Number of Channels 2 Channel

CMRR - Common Mode Rejection Ratio 86.02 dB

Comparator Type General Purpose with Latch

Dual Supply Voltage +/- 3 V, +/- 5 V

GBP - Gain Bandwidth Product -

Height 1.5 mm (Max)

Ib - Input Bias Current 5 uA

Length 8.75 mm (Max)

Maximum Dual Supply Voltage +/- 5.25 V, 5.25 V

Maximum Operating Temperature + 85 C

Minimum Dual Supply Voltage +/- 2.375 V, 4.75 V

Minimum Operating Temperature - 40 C

Mounting Style SMD/SMT

Operating Supply Current 4 mA

Operating Supply Voltage 5 V, 9 V

Output Current per Channel 8 mA

Output Type Complementary

Package/Case SOIC-14

Pd - Power Dissipation 667 mW

Product Analog Comparators

Propagation Delay Time 7 ns

PSRR - Power Supply Rejection Ratio 86.02 dB

Response Time 7 ns

Supply Type Single, Triple

Supply Voltage - Max 10.5 V

Supply Voltage - Min 4.75 V

Technology Bipolar

Type Low Power Comparator

Unit Weight 338 mg

Vos - Input Offset Voltage 4 mV

Width 4 mm (Max)
