Аналоговый компаратор NE521DR2G ON Semiconductor

Артикул:

NE521DR2G

Производитель: ON Semiconductor

Описание: Аналоговый компаратор NE521DR2G ON Semiconductor

Datasheet:

Характеристики

Manufacturer ON Semiconductor

Number of Channels 2 Channel

Dual Supply Voltage +/- 5 V

GBP - Gain Bandwidth Product -

Height 1.5 mm

Ib - Input Bias Current 20 uA

Length 8.75 mm

Maximum Dual Supply Voltage +/- 5.25 V

Maximum Operating Temperature + 70 C

Minimum Dual Supply Voltage +/- 4.75 V

Minimum Operating Temperature 0 C

Mounting Style SMD/SMT

Operating Supply Current 35 mA

Output Current per Channel 20 mA

Output Type Push-Pull

Package/Case SOIC-14

Pd - Power Dissipation 1040 mW

Product Analog Comparators

Reference Voltage No

Response Time 9.6 ns

Supply Type Dual

Supply Voltage - Max 7 V

Technology Bipolar

Type Differential Comparator

Unit Weight 338 mg

Vcm - Common Mode Voltage Negative Rail -3 V to Positive Rail + 3 V

Vos - Input Offset Voltage 7.5 mV

Width 4 mm
