Аналоговый компаратор NJM2901M NJR

Артикул:

NJM2901M

Производитель: NJR

Описание: Аналоговый компаратор NJM2901M NJR

Datasheet:

Характеристики

Manufacturer NJR

Number of Channels 4 Channel

Dual Supply Voltage +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V

GBP - Gain Bandwidth Product -

Height 1.6 mm

Ib - Input Bias Current 250 nA

Ios - Input Offset Current 50 nA

Length 10 mm

Maximum Dual Supply Voltage +/- 18 V

Maximum Operating Temperature + 85 C

Minimum Dual Supply Voltage +/- 1 V

Minimum Operating Temperature - 40 C

Mounting Style SMD/SMT

Operating Supply Current 2 mA

Operating Supply Voltage 36 V

Output Current per Channel 16 mA

Output Type Open Collector

Package/Case DMP-14

Pd - Power Dissipation 300 mW

Product Analog Comparators

Reference Voltage No

Response Time 1.3 us

Supply Type Single, Dual

Supply Voltage - Max 36 V

Supply Voltage - Min 2 V

Technology Bipolar

Type Comparator

Vcm - Common Mode Voltage Negative Rail to Positive Rail 3.5 V

Voltage Gain dB 106 dB

Vos - Input Offset Voltage 7 mV

Width 5 mm
