Аналоговый компаратор TLC3702CDR Texas Instruments

Артикул:

TLC3702CDR

Производитель: Texas Instruments

Описание: Аналоговый компаратор TLC3702CDR Texas Instruments

Datasheet:

Характеристики

Manufacturer Texas Instruments

Number of Channels 2 Channel

CMRR - Common Mode Rejection Ratio 84 dB

Comparator Type General Purpose

GBP - Gain Bandwidth Product -

Height 1.58 mm

Ib - Input Bias Current 30 pA

Ios - Input Offset Current 1 nA

Length 4.9 mm

Maximum Operating Temperature + 125 C

Minimum Operating Temperature - 55 C

Mounting Style SMD/SMT

Operating Supply Current 20 uA

Operating Supply Voltage 3 V to 16 V

Output Current per Channel 8 mA

Output Type Push-Pull

Package/Case SOIC-8

Pd - Power Dissipation 725 mW

Product Analog Comparators

Reference Voltage No

Response Time 1.1 us

Supply Type Single

Supply Voltage - Max 16 V

Supply Voltage - Min 3 V

Technology LinCMOS

Type Micro Power Comparator

Unit Weight 110 mg

Vcm - Common Mode Voltage - 0.2 V to 14.5 V

Vos - Input Offset Voltage 5 mV

Width 3.91 mm
