Аналоговый компаратор TLV3402CDGKRG4 Texas Instruments

Артикул:

TLV3402CDGKRG4

Производитель: Texas Instruments

Описание: Аналоговый компаратор TLV3402CDGKRG4 Texas Instruments

Datasheet:

Характеристики

Manufacturer Texas Instruments

Number of Channels 2 Channel

CMRR - Common Mode Rejection Ratio 88 dB

Comparator Type General Purpose

Dual Supply Voltage +/- 3 V, +/- 5 V

GBP - Gain Bandwidth Product -

Height 0.97 mm

Ib - Input Bias Current 100 pA

Input Type Rail-to-Rail

Length 3 mm

Maximum Dual Supply Voltage +/- 8 V

Maximum Operating Temperature + 125 C

Minimum Dual Supply Voltage 1.25 V

Minimum Operating Temperature - 40 C

Mounting Style SMD/SMT

Operating Supply Current 640 nA

Operating Supply Voltage 2.5 V to 16 V

Output Type Open Collector, Open Drain

Package/Case VSSOP-8

Pd - Power Dissipation 481 mW

Product Analog Comparators

PSRR - Power Supply Rejection Ratio 105 dB

Reference Voltage No

Response Time 80 us

Supply Type Single, Dual

Supply Voltage - Max 16 V

Supply Voltage - Min 2.5 V

Type Nano Power Comparator

Unit Weight 19 mg

Vcm - Common Mode Voltage - 0.1 V to 21 V

Voltage Gain dB 120 dB

Vos - Input Offset Voltage 3.6 mV

Width 3 mm
