Fixed terminal
| Товар | Цена | Color | Conductor cross section flexible | Conductor cross section flexible,with furrule | Conductor cross section rigid | Connection method | Contact material | Contact plating | Degree of pollution | IEC Rated Current | IEC Rated Voltage | Insulation material | Insulation material group | Locking screw Specification | Locking screw torque | Manufacturer | Number of connections | Number of levels | Operating temperature range | Overvoltage category | Pitch | Protection Level | Rated impulse voltage | Stripping length | UL Rated Current | UL Rated Voltage | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.5-16mm² | 0.5-16mm² | 0.5-16mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 76A | 1000V | PA66 | Ⅰ | M4 | 1.2N.m | SUPU | 1 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 10.16 | IP20 | 8.0KV 8.0KV 8.0KV | 10-12mm | 60A 60A – | 600V 600V – | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 2 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 3 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 4 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 5 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 6 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 7 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 8 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 9 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 10 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 11 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | 12 | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-6.0mm² | 0.2-6.0mm² | 0.2-6.0mm² | Screw connection | Copper alloy | Sn,Plated | 3 2 2 | 32A | 1000V | PA66 | Ⅰ | M3 | 0.5-0.6N.m | SUPU | XX | Single layer | -40~+105℃ | Ⅲ/Ⅲ/Ⅱ | 9.52 | IP20 | 6.0KV 6.0KV 6.0KV | 8-9mm | 30A 30A 5A | 300V 300V 600V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 200V | PA66 | Ⅰ | – | – | SUPU | 2 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 160V | PA66 | Ⅰ | – | – | SUPU | 2 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 200V | PA66 | Ⅰ | – | – | SUPU | 2 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 200V | PA66 | Ⅰ | – | – | SUPU | 3 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 160V | PA66 | Ⅰ | – | – | SUPU | 3 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 200V | PA66 | Ⅰ | – | – | SUPU | 3 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 200V | PA66 | Ⅰ | – | – | SUPU | 4 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 160V | PA66 | Ⅰ | – | – | SUPU | 4 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 200V | PA66 | Ⅰ | – | – | SUPU | 4 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 200V | PA66 | Ⅰ | – | – | SUPU | 5 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 160V | PA66 | Ⅰ | – | – | SUPU | 5 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V | |
|
|
поиск предложений
|
Green/Black/Blue/Grey/Orange/Red | 0.2-1.5mm² | 0.2-1.5mm² | 0.2-1.5mm² | Push in connection | Copper alloy | Sn,Plated | 3 2 2 | 17.5A | 200V | PA66 | Ⅰ | – | – | SUPU | 5 | Single layer | -40~+130℃ | Ⅲ/Ⅲ/Ⅱ | 3.5 | IP20 | 2.5KV 2.5KV 2.5KV | 8-9mm | 12A – 10A | 300V – 300V |
