Главная Каталог Разъемы Каталог DEGSON HDC Inserts

Inserts

Сравнить 0 товара

Товар	Цена	830V	Classification	Color	Conductor cross sections(AWG)	Conductor cross sections（mm²）	Connection meets standards	Connection method	Contact resistance	Dimension	Female/Male	Flammability rating	Insulation resistance	Manufacturer	Material（insert）	Materia（Contact）	Number of positions	On the basis of UL /CSARated current	PE Contacts	Pollution level	Rated current	Rated pulse voltage	Rated torque	RoHS	Series	Strip length	Surface（Contact）	Temperature range
D2MK-001-F(25-40mm²) Контактная вставка D2MK-001-F(25-40mm²) Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	4-1AWG	25-40mm²	DIN EN 60664 DIN EN 61984	Axial screw connection	≤0.2mΩ	2 module	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	1	600V	No	3	200A	8KV	8N.m(25/35mm²) 9N.m(50mm²) 10N.m(70mm²)	Comply with RoHS exemptions	DM	16mm	Silver plated	-40℃~+125℃	≥500 time
D2MK-001-F(40-70mm²) Контактная вставка D2MK-001-F(40-70mm²) Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	1-2/0AWG	40-70mm²	DIN EN 60664 DIN EN 61984	Axial screw connection	≤0.2mΩ	2 module	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	1	600V	No	3	200A	8KV	8N.m(25/35mm²) 9N.m(50mm²) 10N.m(70mm²)	Comply with RoHS exemptions	DM	16mm	Silver plated	-40℃~+125℃	≥500 time
D2MK-001-M(25-40mm²) Контактная вставка D2MK-001-M(25-40mm²) Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	4-1AWG	25-40mm²	DIN EN 60664 DIN EN 61984	Axial screw connection	≤0.2mΩ	2 module	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	1	600V	No	3	200A	8KV	8N.m(25/35mm²) 9N.m(50mm²) 10N.m(70mm²)	Comply with RoHS exemptions	DM	16mm	Silver plated	-40℃~+125℃	≥500 time
D2MK-001-M(40-70mm²) Контактная вставка D2MK-001-M(40-70mm²) Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	1-2/0AWG	40-70mm²	DIN EN 60664 DIN EN 61984	Axial screw connection	≤0.2mΩ	2 module	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	1	600V	No	3	200A	8KV	8N.m(25/35mm²) 9N.m(50mm²) 10N.m(70mm²)	Comply with RoHS exemptions	DM	16mm	Silver plated	-40℃~+125℃	≥500 time
D2MK-002-F(10-25mm²) Контактная вставка D2MK-002-F(10-25mm²) Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	8-4AWG	10-25mm²	DIN EN 60664 DIN EN 61984	Axial screw connection	≤0.3mΩ	2 module	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	2	600V	No	3	100A	8KV	8N.m(25/35mm²) 9N.m(50mm²) 10N.m(70mm²)	Comply with RoHS exemptions	DM	13mm	Silver plated	-40℃~+125℃	≥500 time
D2MK-002-F(16-35mm²) Контактная вставка D2MK-002-F(16-35mm²) Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	6-2AWG	16-35mm²	DIN EN 60664 DIN EN 61984	Axial screw connection	≤0.3mΩ	2 module	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	2	600V	No	3	100A	8KV	8N.m(25/35mm²) 9N.m(50mm²) 10N.m(70mm²)	Comply with RoHS exemptions	DM	13mm	Silver plated	-40℃~+125℃	≥500 time
D2MK-002-M(10-25mm²) Контактная вставка D2MK-002-M(10-25mm²) Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	8-4AWG	10-25mm²	DIN EN 60664 DIN EN 61984	Axial screw connection	≤0.3mΩ	2 module	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	2	600V	No	3	100A	8KV	8N.m(25/35mm²) 9N.m(50mm²) 10N.m(70mm²)	Comply with RoHS exemptions	DM	13mm	Silver plated	-40℃~+125℃	≥500 time
D2MK-002-M(16-35mm²) Контактная вставка D2MK-002-M(16-35mm²) Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	6-2AWG	16-35mm²	DIN EN 60664 DIN EN 61984	Axial screw connection	≤0.3mΩ	2 module	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	2	600V	No	3	100A	8KV	8N.m(25/35mm²) 9N.m(50mm²) 10N.m(70mm²)	Comply with RoHS exemptions	DM	13mm	Silver plated	-40℃~+125℃	≥500 time
DA-003-F Контактная вставка DA-003-F Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-16AWG	0.75-1.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	3A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	3	600V	Yes	3	10A	4KV	0.25N.m	Comply with RoHS exemptions	DA	4.5mm	Silver plated	-40℃~+125℃	≥500 time
DA-003-FS Контактная вставка DA-003-FS Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	20-14AWG	0.5-2.5mm²	DIN EN 60664 DIN EN 61984	Spring cage connection	≤1mΩ	3A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	3	600V	Yes	3	10A	4KV	Comply with RoHS exemptions	DA	9.0mm	Silver plated	-40℃~+125℃	≥500 time
DA-003-M Контактная вставка DA-003-M Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-16AWG	0.75-1.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	3A	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	3	600V	Yes	3	10A	4KV	0.25N.m	Comply with RoHS exemptions	DA	4.5mm	Silver plated	-40℃~+125℃	≥500 time
DA-003-MS Контактная вставка DA-003-MS Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	20-14AWG	0.5-2.5mm²	DIN EN 60664 DIN EN 61984	Spring cage connection	≤1mΩ	3A	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	3	600V	Yes	3	10A	4KV	Comply with RoHS exemptions	DA	9.0mm	Silver plated	-40℃~+125℃	≥500 time
DA-004-F Контактная вставка DA-004-F Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-16AWG	0.75-1.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	3A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	4	600V	Yes	3	10A	4KV	0.25N.m	Comply with RoHS exemptions	DA	4.5mm	Silver plated	-40℃~+125℃	≥500 time
DA-004-FS Контактная вставка DA-004-FS Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	20-14AWG	0.5-2.5mm²	DIN EN 60664 DIN EN 61984	Spring cage connection	≤1mΩ	3A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	4	600V	Yes	3	10A	4KV	Comply with RoHS exemptions	DA	9.0mm	Silver plated	-40℃~+125℃	≥500 time
DA-004-M Контактная вставка DA-004-M Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-16AWG	0.75-1.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	3A	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	4	600V	Yes	3	10A	4KV	0.25N.m	Comply with RoHS exemptions	DA	4.5mm	Silver plated	-40℃~+125℃	≥500 time
DA-004-MS Контактная вставка DA-004-MS Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	20-14AWG	0.5-2.5mm²	DIN EN 60664 DIN EN 61984	Spring cage connection	≤1mΩ	3A	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	4	600V	Yes	3	10A	4KV	Comply with RoHS exemptions	DA	9.0mm	Silver plated	-40℃~+125℃	≥500 time
DA-010-F Контактная вставка DA-010-F Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-14AWG	0.75-2.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	10A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	10	600V	Yes	3	16A	4KV	0.5N.m	Comply with RoHS exemptions	DA	7.5mm	Silver plated	-40℃~+125℃	≥500 time
DA-010-FC Контактная вставка DA-010-FC Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	26-12AWG	0.14-4.0mm²	DIN EN 60664 DIN EN 61984	Crimping connection	≤1mΩ	10A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	10	600V	Yes	3	16A	4KV	Comply with RoHS exemptions	DA	7.5mm	Silver plated/gold plated	-40℃~+125℃	≥500 time
DA-010-M Контактная вставка DA-010-M Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-14AWG	0.75-2.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	10A	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	10	600V	Yes	3	16A	4KV	0.5N.m	Comply with RoHS exemptions	DA	7.5mm	Silver plated	-40℃~+125℃	≥500 time
DA-010-MC Контактная вставка DA-010-MC Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	26-12AWG	0.14-4.0mm²	DIN EN 60664 DIN EN 61984	Crimping connection	≤1mΩ	10A	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	10	600V	Yes	3	16A	4KV	Comply with RoHS exemptions	DA	7.5mm	Silver plated/gold plated	-40℃~+125℃	≥500 time
DA-016-F Контактная вставка DA-016-F Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-14AWG	0.75-2.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	16A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	16	600V	Yes	3	16A	4KV	0.5N.m	Comply with RoHS exemptions	DA	7.5mm	Silver plated	-40℃~+125℃	≥500 time
DA-016-FC Контактная вставка DA-016-FC Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	26-12AWG	0.14-4.0mm²	DIN EN 60664 DIN EN 61984	Crimping connection	≤1mΩ	16A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	16	600V	Yes	3	16A	4KV	Comply with RoHS exemptions	DA	7.5mm	Silver plated/gold plated	-40℃~+125℃	≥500 time
DA-016-M Контактная вставка DA-016-M Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-14AWG	0.75-2.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	16A	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	16	600V	Yes	3	16A	4KV	0.5N.m	Comply with RoHS exemptions	DA	7.5mm	Silver plated	-40℃~+125℃	≥500 time
DA-016-MC Контактная вставка DA-016-MC Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	26-12AWG	0.14-4.0mm²	DIN EN 60664 DIN EN 61984	Crimping connection	≤1mΩ	16A	Male	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	16	600V	Yes	3	16A	4KV	Comply with RoHS exemptions	DA	7.5mm	Silver plated/gold plated	-40℃~+125℃	≥500 time
DA-032-F Контактная вставка DA-032-F Degson Degson	поиск предложений	Insert	Grey/White（RAL 7032）	18-14AWG	0.75-2.5mm²	DIN EN 60664 DIN EN 61984	Screw connection	≤1mΩ	32A	Female	V-0	≥10000MΩ	Degson	Polycarbonate（PC）	Copper alloy	32	600V	Yes	3	16A	4KV	0.5N.m	Comply with RoHS exemptions	DA	7.5mm	Silver plated	-40℃~+125℃	≥500 time
